E-4000 | Integrated Amplifier

• Made in Japan

The E-4000 extracts the full potential of any loudspeaker to reproduce sound overflowing with energy and vividness.

Click here for more information

• Revolutionary AAVA volume control
• Four-fold parallel push-pull configuration of power transistors driven in Class AB
• High power output of 180 watts into 8 ohms / 260 watts into 4 ohms
• Power amplification stage configured as instrumentation amplifier
• High damping factor of 800
• Strong power supply with massive high-efficiency toroidal transformer
• High-voltage, large filtering capacitors
• Protection circuitry using MOS-FET switches
• Dimensions: Width 465 mm (18.3”) × Height 181 mm (7.1”) × Depth 428 mm (16.9”)
• Weight: 24.4 kg (53.8 lbs)

5 years
