Quintet Blue | MC Phono Cartridge

• Coup de Coeur
• Very homogeneous
• Made in Denmark

• What Hi-Fi?

The Quintet Blue features a bare elliptical diamond mounted on an aluminum cantilever. It is a very good choice for any type of music, especially rhythmic.

Click here for more information

• Output voltage at 1 kHz 5 cm/sec - 0.5 mV
• Channel balance - < 1.5 dB
• Channel separation at 1 kHz - > 21 dB
• Channel separation at 15 kHz - > 14 dB
• Frequency response 20-20,000 Hz - +/-2.5 dB
• Tracking ability at 315 Hz at recommended tracking force *) - 70 μm
• Compliance, dynamic, lateral - 15 μm/mN
• Stylus type - Nude Elliptical
• Stylus tip radius - r/R 8/18 μm
• Tracking force range - 2.1-2.5 g (21-25 mN)
• Tracking force recommended - 2.3 g (23 mN)
• Tracking angle - 20º
• Internal impedance, DC resistance - 7 Ohm
• Recommended load impedance - >20 Ohm
• Cartridge body material - ABS/Aluminium
• Coil wire material - Pure 4-nines silver
• Cartridge weight - 9g

1 year
